Designed for areas where cold air is not desired to be directly on the products. Ideal for commercial applications and small volumes. Cooling is floor-to-ceiling in one or two directions. High performance and energy efficiency.
Outstanding Features:
Plastic-cabin ceiling-type evaporators are equipped with advanced cooling systems, ensuring high performance. Energy efficiency allows users to reduce energy costs while minimizing environmental impact. These technologies provide reliable cooling even in varying climate conditions. Users benefit from increased cooling power with less energy consumption.
Plastic-cabin ceiling-type evaporators are designed with features that simplify user experience. Quick installation processes minimize downtime during setup, allowing businesses to meet their cooling needs faster. Maintenance is straightforward and organized, enabling even users without technical knowledge to perform it easily.
Ceiling type evaporators with plastic cabinets offer high performance while saving energy thanks to optimised cooling technology.
Advanced material quality guarantees a long-lasting and durable performance even in harsh conditions.
User-friendly design offers fast installation processes, thus minimising time loss.
Can be used effectively in different sectors and climatic conditions, providing flexibility with a wide range of applications.
Manufactured in pipe diameter of 3/8" with wall thickness of 0,35 mm in a staggered arrangement. Aluminum fins with a corrugated surface are used, with a fin spacing of 4,5 mm, and the mold geometry is designed as 32x28 mm. To protect the copper pipes used in the batteries, mirror sheets are made of aluminum. A Refrigerant Distributor and Copper Collector are used.
GNK Series Plastic Ceiling Type Evaporators' cabinets are manufactured from galvanized steel, painted with RAL 9016 electrostatic powder paint, which is resistant to different weather conditions.
GNK Series Plastic Ceiling Type Evaporators use fans with diameters of Ø250, Ø300 mm.
Optional E1 or E2 electric defrost application can be provided upon request.
Capacities are calculated according to EN 328 Standards for R404A refrigerant gas based on European fans.
The GNK Series Plastic Ceiling Type Evaporators are tested at 40 bar and shipped with 6 bar nitrogen.
